AirMaster 4100P


Physical & Environmental

Power

DC 24V/0.5A PoE Adapter <15W

Weight

<1.5Kg

Dimensions

310mm(L) * 122mm(W) * 75mm(D)

Environment

Operating Temperature, -40~55. Humidity, 95% max Non-condensing

Water Resistance

IP67

LTE Radio Interface

Radio Access

3GPP LTE Release 9, Category 4

Operation Mode

1T2R, TxD, DL 2x2 MIMO, Optional UL QAM64 Support

Frequency Band

B38/40/41, B42/43/48

Channel Bandwidth

1.4/3/5/10/15/20 MHz

QoS Support

Non-GBR and GBR

Max Tx Power

23dBm

Antenna Gain

B38/40/41: 10dBi, B42/43/48: 12dBi

User Interface

Data Interface

1 RJ45 10/100M ETH Ports

LED Indicator

SYS, SIM, ETH, RF (4 Signal intensity LEDs)

SIM Card

Single USIM Card Slot (2FF)

Configurations & Management

LTE Networking

Multiple PDN interface support, IPv4 & IPv6 Networking Support, APN, Channel and Band Configuration, Network Selection and Cell Locking Provision, SIM Card Locking Feature.

Basic Data Networking

Router and L3 Bridge Operation Mode Support, Built-in DHCP Server for LAN Devices, VPN Pass-through support (PPTP, L2TP and IPSEC), Firewall & Access Control, DMZ and Virtual Server Support, IP and Port Filtering Support, NTP Service Support.

Advanced Networking Features

Built-in L2TP L2/L3 Tunneling client support, Built-in GRE L2/L3 Tunneling client support, Device Management Access Control, Application Firewall Support, LAN Device Access Control.

Device Management

CLI, Secure Telnet and WEB Management Interfaces, Standard TR-069 Management, OTA Upgrade Support (http, ftp, and TR069), Dual Image Bank Support for Safe Upgrade, Device Factory Default Setting.





Preview picture




Feature Highlights

  • Cost effective & compact design with built-in high gain LTE MIMO antennas
  • Compliant to 3GPP LTE R9 specifications
  • Advanced DL MIMO, UL QAM64 Optional and Category 4 throughput
  • Router, bridge and by-pass networking, IPv4 & IPv6 and Multiple PDN support
  • USIM card authentication support
  • Secure Telnet, FTP, HTTP and TR069 OTA management support
  • Router, bridge and by-pass networking, IPv4 &v6 and Multiple PDN support
  • FTP, HTTP, HTTPS and TR-069 management support
