Physical & Environmental

Power

24V DC PoE Adapter

Weight

2.5kg

Dimensions

151mm(L) * 239mm(W) * 54mm(D)

Environment

Operating Temperature, -40℃~55℃. Humidity, 90% max Non-condensing

WiMAX Radio Interface

Radio Access

IEEE 802.16e Wave2 WiMAX

Operation Mode

1T2R, DL 2x2 MIMO, QAM64 Support

Frequency Band

5091~5150MHz

Channel Bandwidth

3 / 3.5 / 5 / 7 / 8.75/ 10 MHz

Max Tx Power

21dBm

Modulation

QPSK, 16QAM, 64QAM

Base Band Support

MIMO A&B, ARQ, HARQ

FFT

1024/512 FFT points

FEC

Convolution and Turbo Code

Authentication

TTLS/TLS

Antenna Connector

2 N-Type

User Interface

Data Interface

1 RJ45 10/100M ETH Ports, 1 RJ11 Line Port (Optional)

LED Indicator

Power Status, System Status, LAN, WiMAX RF Signal (6 LEDs)

Voice Features (Optional)

VoIP Processing

Compression G.711 G.721 G.723 G.726 G.729 G.722, Comfort Noise Comfort noise generation & control, Echo Cancellation G.165/168-2000, Silence Handling Silence detection/suppression, Fax Support T.30 and T.38, Delay/Jitter/Loss Jitter and packet loss compensation, DTMF Relay in band DTMF, RFC2833, SIP signal, Call Duration 24+ hours Uninterrupted Call.

Voice Services

[Basic Voices]: Local, domestic & international calling, Flexible dial plan configuration support, Tone customization for different countries.

[Supplement Services]: Caller ID, Caller ID suppression, Call Screening, Speed dial, Call Tracing, Hotline, Unconditional call forwarding, Call Forwarding No Answer, Call Forwarding on Busy, Call Waiting, Call Back, Call Blocking, No Disturbance, Alarm, Network and Local 3-way Call, Data Call, and etc.

Configurations & Management

Network Configuration

DHCP or static IP address assignment

Bridge and Router Operation Support

Built-in DHCP Server for LAN devices

Data Networking Features

Built-in PPPoE Client Support for LAN Interface

Voice, Data and Management Traffic Classification

802.1p/q, DSCP or TOS Marking

VLAN Classification and Tagging Support

VPN Pass-through Support (PPTP, L2TP and IPsec)

IP Filtering, Virtual Server and SPI Firewall

LAN Device Access Control

Device Management

CLI, Secure Telnet and WEB Management Interfaces, Standard TR-069 Management, Device Factory Default Setting.
